Stepper Motor Drive Card V3 (RASB) (A)
This stepper motor drive card V3 drives the RASB stepper motor, which turns the RASB carrousel wheel where samples can be loaded and are tested automatically according with the sequence created on the software.
Note
The stepper motor drive card V3 (RASB) is only compatible with the stepper motor assembly V2 (RASB).
Mounting
The board is inserted in the upper terminal box on 2nd position starting on left side.
Please refer to the device user manual and electrical drawings, or contact the customer support at service@hitec.lu.
Additional information
| Weight | 0,13 kg |
|---|---|
| Dimensions | 18,5 × 10,0 × 3,3 cm |
