Strain Gauge Card (A)
The “Strain Gauge Card” manages the “Strain Gauge” and retrieves the readings to the “CPU Card”.
The “Strain Gauge” cable is connected to the front connector, and the reading values are adjusted respectively with the respective potentiometers.
Note
The “Strain Gauge” might also be mentioned in general as “Load Cell”.
Mounting
The board is inserted in the upper terminal box on 4th position (counted from the left side).
Please refer to the device user manual and electrical drawings, or contact the customer support at service@hitec.lu.
Additional information
| Weight | 0,47 kg |
|---|---|
| Dimensions | 17,0 × 11,5 × 4,0 cm |
