Stepper Motor Drive Card V2 (IPHT) (A)
The stepper motor drive card V2 drives the stepper motor V2.
This board on the IPHT drives the stepper motor to move the pellet support.
Note
The stepper motor drive card V2 is only compatible with the stepper motor assembly V2.
Mounting
The board is inserted in the upper terminal box on 2nd position starting on left side.
Please refer to the device user manual and electrical drawings, or contact the customer support at service@hitec.lu.
Additional information
| Weight | 0,13 kg |
|---|---|
| Dimensions | 18,5 × 10,0 × 3,3 cm |
